Spare Parts

Connecting tower with a metal screw and plastic connector to connect to wire and plastic parts respectively.

Bent Marble Run track of 7 units.

NOT block to complement the input from 1 to 0 or 0 to 1.

A cable to connect the sensors and output devices to the boffin controller.

Long 2 x AA cell battery holder.

470 microfarad capacitor with wires to add 470 microfarad capacitance to the circuit.

An Output Device.

Red LED with two polarity terminals, produces red light as output when supplied with 3V power.

The 3V coin cell 2 batteries are required to power Queaky.

IR Sensor to detect the presence of an object in front of it. This sensor attaches to a controller.

Servo motor, an output device controlled by a controller. It can rotate from 0 to 180 degrees.

LED block, an output device. LED turns On when the input is 1, it is Off when the input is 0.

This is to connect the motor in boffin.

Buzzer block that gives sound as output when input is 1, off otherwise.

 A battery box with two push buttons.

It is the base where it connects the different IC's.

It's a part of discovering electronics and this is a module from where we give the on and off input.

It's a PCB component in discovering electronics that houses resistance, capacitance, LED, and POT connections.

A component in discovering electronics used to digitally display numbers from 0 to 9.

 Acts as a digital Input block in logic blocks kit.

A Controller Board to connect various inputs and outputs.

127mm diameter circular rainbow colored fan.

Long connecting wire.

Long alligator-style black clip with wire to connect to e-circuit parts.

Long alligator style red clip with wire to connect to e-circuit parts.

Ecircuit motor with two terminals.

LDR controls the current flow in the circuit depending on the intensity of light.

Potentiometer is a variable resistor controlled by a knob.

3.3K ohm resistor with wires to add 3.3k ohm resistance to the circuit.

20k ohm resistor with wires to add 20k ohm resistance to the circuit.

10K ohm resistor with wires to add 10k ohm resistance to the circuit.

Slide Switch with two terminals, used to make or break the electrical circuit.

Green LED with two polarity terminals, produces green light as output when supplied with 3V power.

Push button switch with two terminals, used to make or break the electrical circuit.

A screwdriver is used for the insertion and removal of screws

Ultrasonic sensor to measure the length of an object in front of it. This sensor attaches to a controller.

A sensor to detect any change of movement.

A Sensor to detect temperature and humidity.

Sound sensor to detect the presence or absence of sound. It attaches to a controller.

A Sensor to detect moisture in the soil.

A Sensor to detect whether somebody is in proximity.

The programming cable is to download the code into your controller.

Limit switch that acts as an input. This sensor attaches to a controller.

Light sensor to detect the presence or absence of light. It attaches to a controller.

The encoder is used to count the number of rotations.
